2835 SMD 12V 24V LED Module Modular Light Constant Current Injection White For Channel Letter
Product Details:
Place of Origin: | China |
Brand Name: | ADLED |
Certification: | UL/CE/RoHS |
Model Number: | ADM-6221-2835-2 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1000pcs |
---|---|
Delivery Time: | 7days |
Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
Supply Ability: | 100000pcs |
Detail Information |
|||
Name: | 2LEDs 2835 LED Module Light | Model: | ADM-6221-2835-2 |
---|---|---|---|
Voltage: | DC12V/24V | LED Quantity: | 2LEDs |
Watts Per Metre: | 2W | Colour Temperature: | 3000K/4000K/6500K |
IP Rating: | IP67 | Driven Mode: | Constant Current |
Beam Angle: | 180° | Warranty: | 5 Years |
Highlight: | Modular 24V LED Module,24V LED Module,2835 SMD LED Module |
Product Description
LED Modules Modular Light Injection 2835 SMD White 12V 24V for Channel Letter
Benefits of LED Module Lights
1. LED Module
Our led module series powered by brand LEDs, which helps for durable long life span.
2. 180° view angle
LED modules emit 180 degree, more uniform lighting in channel letter sign.
3. Unique lens
Our reimagined LED prism lens of LED modules with a wider light spot, P:D=3.5:1, normal bat-wing lens in market is 2:1.
![]() |
![]() |
Normal bat-wing lens in market | ADLED reimagined LED prism leds technology |
size: Φ12.1*H4.5mm P:D=2:1 |
size: Φ15.23*H5.55mm wide light spot P:D=3.5:1 |
4. High Power LED Module
We make 1w, 2w, 2.5w, 3w LED module as standard, high power LED module always has high brightness, nice choice for LED channel letter signs and large light box sign.
![]() |
![]() |
![]() |
![]() |
ADM-3621-2835-1 Power: 1W |
ADM-6221-2835-2 Power: 2W |
ADM-8821-2835-3 Power: 2.5W |
ADM-5246-2835-4 Power: 3W |
LED Module Lights Manufacturer
ADLED focus on premium LED module manufacturer in China, served 106 countries up to now.
As a professional one stop solutions provider of illuminated channel letter signs, ADLED also provide LED Power supply for our partners.
Waterproof LED module is a good light source for indoor & outdoor LED signage.
What is LED Module Lights?
LED Module Lights is simply encapsulate diodes together, and make it waterproof, like injection or ultrasonic process. It is best lighting solution for led channel letter signs or light boxes.
Various LED Module Lights available.
Different Series: Samsung LED module, LED module, Mini LED module, Bright LED module, High power LED module, RGB LED module, Edge lit LED module, High Efficiency LED Module.
Different Brand chips: Philips, Samsung, , Sanan
Different LEDs: 1led, 2leds, 3leds, 4leds
Different Voltage: 12v LED module, 24v LED module, AC LED module
Different colors: Warm white, Natural White, White, Cool White, Red, Green, Blue, Yellow, RGB
LED Module Lights Specification:
Model | ADM-6221-2835-2 |
LED type | LED 2835 SMD |
LED Quantity | 2LEDs |
Operating voltage | DC12V/24V |
Power | 2W |
Colour temperature | 3000K/4000K/6500K |
IP rating | IP67 |
Beam angle | 180° |
Warranty | 5 Years |
Driven Mode | Constant Current |
Certifications | UL/CE/RoHS |
Size | 62*21*8.1mm |
Dimmable | 0-100% dimmable by LED strip light dimmer |
LED Module Lights Application:
• 3D Letters Lighting
• Light Boxes Lighting
• Back Lighting
• Commercial Lighting
• Curved Displays Lighting
• Freeze Lighting
• Light bar Light Source
• Retail Display Lighting
LED Module Lights FAQ
Q: Can I get free samples of LED module lights?
Yes, usually we can provide free samples for you to check quality. You can mix all LED modules series.
Q: What is delivery time for LED light modules?
LED module lights is our top selling series, 3days for samples, 15days for 50000pcs, 30days for 300000pcs.
Q: Is LED module price expensive?
We are LED module factory, LED module series is relatively cheap.
Q: Do you provide ODM ?
Yes, our strong R&D team successfully develop and ODM smd LED module over 30 types.
