Top Rated Tunable White Led Strip COB CCT Dotless Lights DC 24V Adjustable 2700K To 6500K
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL/CE/RoHS |
| Model Number: | ADS-YCOB-640CCT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100M |
|---|---|
| Packaging Details: | 5m(16.4ft) Per Roll |
| Delivery Time: | 7days |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 100000M |
|
Detail Information |
|||
| Name: | Top Rated Tunable White Led Strip COB CCT Dotless Lights DC 24V | Model: | ADS-YCOB-640CCT |
|---|---|---|---|
| Voltage: | DC24V | LEDs Per Metre: | 640 |
| Watts Per Metre: | 16W | Color: | 2700K To 6500K |
| IP Rating: | IP20/IP65/IP67/IP68 | Beam Angle: | 180° |
| Warranty: | 3 Years | PCB Width: | 10mm |
| Package: | 5m/roll | Cutting Unit: | 50mm |
| High Light: | Dotless Tunable White Led Strip,Tunable COB CCT Dotless Lights,Tunable White Led Strip DC24V |
||
Product Description
top rated tunable white led strip COB CCT dotless lights DC 24V adjustable 2700K to 6500K
Introduction of Tunable white COB LED Strip
Uncover superior illumination with ADLED's cob cct Tunable White LED Strip. This 5m roll utilizes a unique single-chip per LED design, ensuring unparalleled color consistency unlike the inconsistent double-chip LEDs found in cheaper alternatives. With 640 COB LEDs per meter, adjustable color temperature, and external resistors for enhanced cooling, our led lighting strips sets the standard in LED technology. We are committed to delivering premium, long-lasting lighting solutions.
The adjustable color temperature ranges from a warm 2700K to a cool 6500K. Each warm and cool white channel emits a robust luminous flux of 800 lumens per meter while consuming 7.5W per 340 LEDs per meter, bringing the total power output to an impressive 15W/m.
Please do NOT connect more than 5 meters of strip cob led in series. A led tape lights exceeding 5 meters in length is overloaded due to the increased amount of current passing through, resulting in the damage of the PCB and the failure of the good led strip lights. Thus, when exceeding 5 meters of tape lights, it is suggested to connect the tape light directly to the LED controller or driver using a 2-core cable.
Benefits of COB dual LED Strip
1. Seamless dual white LED Strip
Hot spot lights of traditional dual white ledstrip are bad for eyes, cob led strip lights emit uniform brightness, shines in one straight line, it emits perfect lighting even without LED aluminum profile.
2. More Flexible Adjustable led strip lights
640 chips combines in one meter best adjustable led strips, the space between two chips is ultra narrow, you can bend arbitrarily the tunable led strip lights without any damages.
3. White and amber LED Strip
A dual led strip light can bring you countless led cob strip, those chip on board led strip color temperature changes from 2700K to 6500K.
|
4. 180° Beam Angle |
|
5.Types of CCT COB LED
The ww cw led strip of ADLED have 2835 tunable led strip, 3528 cct strip, 315 side emitting dual color led strip lights, smd 5050 cw ww led strip and cob led strip dual white.
Best Tunable White LED Strip lights Manufacturers
|
|
|
What is Adjustable Strip?
led light strip two different colors is a type of COB Strip, also belongs to tunable white stripe.
2 color led strip help you adjust various white colors according to your requirements, usually in a range of 2700K to 6500K color temperature.
This tunable tape light shines in one straight line, also can adjust white colors, an idea LED light strips for commercial lighting.
COB CCT LED Strip Specifications:
| Model | ADS-YCOB-640CCT |
| LED type | COB (Chip On Board) |
| LEDs per metre | 640 |
| Operating voltage | DC24V |
| Watts per metre | 8W |
| Color | CCT |
| IP rating | P20/IP65/IP67/IP68 |
| PCB width | 10mm |
| Cut points | 25mm(0.98'') for 24V |
| Beam angle | 180° |
| Warranty | 3 Years |
| Certifications | UL/CE/RoHS/ErP |
| Package | 5m(16.4ft) per roll |
| Dimmable |
0-100% dimmable by LED strip light dimmer |
Tunable White COB LED Strip Dimensions:
COB CCT Strip Light Application:
warm and cool white led strip are widely used in shopfitting, interior deisgn, linear LED Lighting and commercial lighting.
What other customers say about LED Stripe tunable white
CCT LED Strip Accessory
CCT LED Strip 24v FAQ:
Q: Why more and more people choose bi color led strip?
dotless led strips has many big advantages compared with SMD LED strip, such as perfect linear lighting effect, more flexibility, etc. With advanced craft, it can produce more perfect CRI and color temperature values.
Q: Can you link dotless led strip?
Yes, you can link seamless led strip easily. We can provide lots of spotless led strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips ledstrip cob.
Q: Is cob led tape dimmable ?
Yes, you can dim these led cob strip lights with a simple LED dimmer.
Q: Can you make waterproof strip led cob?
Yes, we can make waterproof led cob strip light IP65, IP67, IP68 for different lighting applications.
Q: Do cob led 24v need aluminum profile for heat dissipation?
Yes, LED aluminum profile can help cob led strip 24v to dissipate heat better and prolong the life of the cob led stripe.
