COB Led Strip Light 504leds/m 5 Meter DC12V/24V 3000K Color Temperature IP20 Rated Blue Backing Adhensive
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL,CE |
| Model Number: | ADS-YCOB-504 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500M |
|---|---|
| Packaging Details: | Static bag |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| LED Type: | COB LED | LED Quantity: | 504Leds |
|---|---|---|---|
| PCB Width: | 10MM | Ra: | 80+ |
| Power: | 12W/M | Working Voltage: | DC12V/24V |
| Color: | 2700K/3000K/4000K/6500K | Strip Length: | 5m |
| Cutting Length: | 17.86mm For DC12V, 41.67mm For DC24V | IP Rating: | IP20 |
| Working Temp: | -20～40 | Lifespan: | 50,000H |
| Warranty: | 2 Years | ||
Product Description
COB Led Strip Light 504leds/m 5 Meter DC12V/24V 3000K Color Temperature IP20 Rated Blue Backing Adhensive
Description
The 504 series is a high-density COB light strip with 504 LED chips installed on a 1m long light strip. The LED chips are arranged at intervals of 1.98mm. The 12V 504 light strips can be cut every 17.86mm, and the 24V 504 light strips can be cut every 41.67mm. When turned on, the dome-shaped phosphor gel on the surface emits light in a straight line evenly and at a large angle. The high brightness and high CRI, and spot-free COB light strip can make your lighting clearer. It is also loved by many people.
Features
Chip-on-board design, up to 504 chips on single meter reaches even and uniformlighting.
17.86mm cutting length for DC12V,41.67mm cutting length for DC24V.
New circuit design to reduce brightness difference from beginning and ending.
Double layyer 2oz PCB, balancing voltage dropping, heat dissipation and flexibility
Dimension
Cutting Length
Technical parameters
Installation Ways
The max running length is 5 meters, for over 5 meters please connect in parallel.
Make sure of the total watts of COB Strip lights is less than 80% of the power supply's max output.
Match the polarities according to the mark ('+' and '-') in the PCB while connecting.
Application
1. Light up colorful home life, DIY home lights are suitable for corridors, stairs, and walkways, and are widely used in home decoration, hotels, clubs, shopping malls,
2. Emergency and safety lighting, advertising sign lighting,
3. Architectural decorative lighting, high-quality atmosphere lighting,
4. Decorative lights for festivals, events, performances and exhibitions,
5. Widely used in backlighting, concealed lighting, trough lighting,
6. Suitable for car decoration, frame or contour lighting.
Questions & Answer
Q1: How to ensure high quality?
A1: 1. We have our own material production workshop and mold factory.
2. Workers should receive good training before taking up their jobs.
3. 100% QC online and final inspection, no defective products can leave our factory.
4. We have many certificates to ensure our quality, such as UL/CE/ROHS certificates, etc.
Q2: Can you provide customized services?
A2: Yes! We have professional designers who can provide you with free designs. Please send us your requirements!
Q3: If I need samples, can you support?
A3: We can provide you samples for free, but the shipping cost will be borne by our customers. To avoid misunderstanding, please provide an international express account with freight collect, which would be greatly appreciated.
Q4. If we need customization, how to order customized LED lights?
A4: First let us need to know your requirements or application areas so that we can give you better suggestions.
Second we need to make a quotation based on your requirements or our suggestions, and we will do our best to provide a competitive price.
Third, after the customer confirms the sample and pays the deposit, the order becomes official.
Fourth, we ask our factory to arrange production.
Q5. How do you ship goods and how long does it take to arrive?
A5: We usually ship via DHL, FedEx. Usually takes 3-5 days to arrive. Air and sea shipping are also optional.
Q6. What is your delivery time?
A6: For sample order the delivery time is 3-5 days.
It takes 10-15 days for small batch orders, or it depends on the customer's demand.
For larger orders, we need to negotiate the delivery time to give the customer the best delivery date.
Q7. How long is the warranty period of your products?
A7: We provide 2-5 years warranty for our products.
About Us
Founded in 2013, ADLED is a high-end LED strips and LED modules supplier headquatered in Shenzhen, China.
ADLED has 300 staff working in a 12000sqm dust-free workshop, 15 professional R&D members, 30 experienced QC members to provide customization & quality products.
Our wide range of LED strips and LED modules includes high CRI LED strip, COB LED strip, single color LED strip, RGB LED strip, tunable white LED strip, bendable LED strip, waterproof LED strip, neon LED strip, light bars for LED fabric frame, bar light for LED light box, LED module lights, SMD LED module, LED strip connector, LED strip profile, LED strip controller, and more.
ADLED provide full OEM & ODM services for LED Channel letters, LED Light boxes and linear lighting solutions.
We have big advantages on OEM & ODM service, like low MOQ requests, free or low cost, professional R&D team, design in a quick time, etc.
In the past 10 years, we develop different types of led lights strips, LED light box sign solutions, smd led module.
