5 Meter COB Led Strip Light 528led/m DC12V 4000K Color Temperature IP20/IP54/IP65/IP67 Rated with 3 Year Warranty
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL,CE |
| Model Number: | ADS-YCOB-528-12-8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500M |
|---|---|
| Packaging Details: | Static bag |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| LED Type: | COB LED | LED Quantity: | 528Leds |
|---|---|---|---|
| Working Voltage: | DC12V | Power: | 10W/M |
| Color: | 2700K/3000K/4000-6000K | Ra: | 80+ |
| PCB Width: | 8MM | Strip Length: | 5m |
| Cutting Length: | 7.58MM | IP Rating: | IP20/IP54/IP65/IP67 |
| Working Temp.: | -20～40 ℃ | Warranty: | 3 Years |
| Viewing Angle(°): | 180 | Application: | Moving Head Light, COB LED Grow Lamp, LED Tube Light, Ect., Garden Yard Pathway |
Product Description
5 Meter COB Led Strip Light 528led/m DC12V 4000K Color Temperature IP20/IP54/IP65/IP67 Rated with 3 Year Warranty
Description
The ADLED528COB light strip is composed of 528 chips per meter. The high-density chips make the lighting of the entire light strip look spotless and very bright. only 1.89mm distance between chips.Only 7.58mm cutting length, suitable for more applications. It can be used in cabinets, shopping malls, linear lighting, display cabinets, and home decoration. exert its effect.
Features
Chip-on-board design, more chips on board reaches even and uniform lighting.
Up to 528 chips, only 1.89mm distance between chips.
Only 7.58mm cutting length, suitable for more applications.
Double layer 2oz PCB, balancing the voltage drop, heat dissipation and flexibility.
IP20/IP54/IP65/IP67 optional
Dimensions
Technical parameters
Installation Ways
The max running length is 1 meters, for over 1 meters please connect in parallel.
Make sure of the total watts of COB Strip lights is less than 80% of the power supply'smax output.
Match the polarities according to the mark ('+' and '-') in the PCB while connecting.
Package
Applications
Display cabinets, cupboards, sideboards, wardrobes and even Staris lighting sources.
