528 LEDS/M Ultra Slim COB LED Strip Lights Flexible Linear Light Tape DC12V 5W
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL/CE/RoHS |
| Model Number: | ADS-YCOB-528-12-4.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100M |
|---|---|
| Packaging Details: | 5m(16.4ft) Per Roll |
| Delivery Time: | 7days |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 100000M |
|
Detail Information |
|||
| Name: | 528 LEDS/M COB RGB LED Strip Light | Model: | ADS-YCOB-528-12-4.5 |
|---|---|---|---|
| Watts Per Metre: | 5W | Voltage: | DC12V |
| LEDs Per Metre: | 528 | Color: | 2700K/3000K/4000K/6500K |
| IP Rating: | IP20/IP67 | Warranty: | 3 Years |
| Beam Angle: | 180° | PCB Width: | 4.5mm |
| High Light: | Ultra Slim COB LED Strip,Linear Light Tape DC12V,COB LED Strip 5W |
||
Product Description
Wholesaler Ultra Slim COB LED Strip Lights Flexible Linear Light Tape
1. Feature of Ultra Slim COB LED Strip
Designed with Chip-on-Board, more chips on PCB to reach even and uniformlighting effects.
Up to 528 chips per meter, only 1.89mm distance between chips.
Ultra slim in 4.5mm width, more applications.
Double layer 2oz PCB, for better flexibility, heat dissipation and voltage drop
IP20/IP65 optional
2. Higher Brightness
With 528 LEDs per meter, the Ultra Thin COB LED strip can provide a significantly higher level of brightness compared to standard LED strips. This makes it suitable for applications where intense illumination is required, such as display lighting, signage, or areas with high ambient light.
3. Space-saving Design:
The "Ultra Thin" feature implies that the LED strip has a slim profile and occupies minimal space. This makes it easier to install in tight spaces or applications where size constraints are a concern. The thinness of the strip allows for more discreet and flexible installation options.
|
4. 180° Beam Angle
|
|
5. Flexibility:
The Ultra Thin COB LED strip is typically designed to be highly flexible, allowing it to conform to curved or irregular surfaces. This flexibility opens up a wider range of creative possibilities for lighting designs and installations. It can be bent, twisted, or shaped to fit various architectural features or creative lighting projects.
LED Strip Supplier
|
All our best light strips are of UL, CE, RoHS certified products, guarantee a 3 or 5 years warranty. |
|
Uniform illumination:
COB LED technology ensures a high level of uniformity in light distribution across the strip. With 528 LEDs per meter, the Ultra Thin COB LED strip provides consistent illumination without visible gaps or dark spots. This results in a smooth and even lighting effect.
COB LED Strip Specifications:
| Model | ADS-YCOB-528-12-4.5 |
| LED type | COB (Chip On Board) |
| LEDs per metre | 528 |
| Operating voltage | DC12V |
| Watts per metre | 5W |
| Color | 2700K/3000K/4000K/6500K |
| IP rating | IP20/IP67 |
| PCB width | 4.5mm |
| Cut points | 22.73mm |
| Beam angle | 180° |
| Warranty | 3Years |
| Certifications | UL/CE/RoHS/ErP |
| Package | 5m(16.4ft) per roll |
| Color changeable |
Color jumping or gradient controlled by LED COB tape controller |
COB LED Strip Application:
• Interior lighting
• Under-cabinet lighting
• General illumination
• Entertainment lighting
• Stage lighting
• Task lighting
• Decorative lighting
• Ceiling lighting
COB LED Strip FAQ:
Q: Why more and more people choose COB LED tape?
COB LED tape has many big advantages compared with SMD LED strip, such as perfect linear lighting effect, more flexibility, etc. With advanced craft, it can produce more perfect CRI and color temperature values.
Q: Can you link LED strip lights?
Yes, you can link LED strip lights easily. We can provide lots of LED strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips COB LED strip.
Q: Is COB LED strip dimmable ?
Yes, you can dim these dimmable COB LED strip with a simple LED dimmer.
Q: Can you make waterproof COB LED strip?
Yes, we can make waterproof COB LED strip IP65, IP67, IP68 for different lighting applications.
Q: Do COB LED strip need aluminum profile for heat dissipation?
Yes, LED aluminum profile can help COB light strip to dissipate heat better and prolong the life of the COB light strip.
