Indoor 528led/M COB LED Strip 3000K DC12V Ultra Slim 3MM Width IP20/IP65 With CE/ROHS
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL,CE,ROHS |
| Model Number: | ADS-YCOB-528-12-3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500M |
|---|---|
| Packaging Details: | Static bag |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| LED Type: | COB LED | LED Quantity: | 528Leds |
|---|---|---|---|
| Working Voltage: | DC12V | Power: | 4W/M |
| Ra: | 80+/90 | Color: | 2700k/3000k/4000-6000k |
| PCB Width: | 3MM | Strip Length: | 1000mm |
| Cutting Length: | 22.73MM | IP Rating: | IP20/IP65 |
| Working Temp: | -20-40 °C | Warranty: | 2 Years |
| Viewing Angle: | 180 | ||
| High Light: | IP65 Led Strip Light DC12V,528led/M Ultra Thin Led Light,3MM Width COB LED Strip |
||
Product Description
528led/m COB Led Strip Light 3000K DC12V Ultra slim 3MM Width IP20/IP65 Rated With CE/ROHS For Indoor Decorations
Description
ADLED LIGHT 528led/m COB led strip light. Each meter is composed of 528 lamp beads. The very high-density lamp beads cover the entire light strip, breaking the traditional SMD light strip design of one lamp bead one by one. Make the light strip brighter and without spots. The extremely thin 3mm PCB board width can be hidden in every corner without destroying the original beauty. The low voltage of DC12V makes the use of light strips safer.
Features
Designed with Chip-on-Board, more chips on PCB to reach even and uniformlighting effects.
Up to 528 chips per meter, only 1.89mm distance between chips.
Ultra slim in 3mm width, more applications.
Low voltage input in 12Vdc.
IP20/IP65 optional.
Dimensions
Technical parameters
Installation Ways
￭ The max running length is 1 meters, for over 1 meters please connect in parallel.
￭ Make sure of the total watts of COB Strip lights is less than 80% of the power supply'smax output.
￭ Match the polarities according to the mark ('+' and '-') in the PCB while connecting.
Package
Applications
--Used in linear lights as lighting source; used for indoor decorations.
