Indoor 810led/M COB LED Strip DC12V RGB Full Color IP20/IP65 Rated With CE Listed
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL,CE,ROHS |
| Model Number: | ADS-DCOB-810RGB-12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500M |
|---|---|
| Packaging Details: | Static bag |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| LED Type: | COB LED | Working Voltage: | DC12V |
|---|---|---|---|
| Color: | R/G/B/Mix | Ra: | 80+ |
| PCB Width: | 10MM | Strip Length: | 5m |
| Cutting Length: | 33.33MM | IP Rating: | IP20/IP65 |
| Working Temp.: | -20～40 ℃ | Warranty: | 3 Years |
| High Light: | 810led/M COB Led Strip,IP65 Rated COB LED Strip,CE DC12V RGB LED Strip |
||
Product Description
810led/m COB Led Strip Light DC12V RGB Full Color IP20/IP65 Rated With CE Listed For Indoor
Description
ADLED LIGHT COB 810RGB strip light, red, green, yellow and mixed white, the rich colors make the light strip wonderful and dreamy. With 810 lamp beads per meter, the brightness of the light strip reaches its highest level. It can be cut every 33.33mm and can be flexibly used for various decorations. The COB light strip has no light spots, can be cut, can be bent, and has good heat dissipation performance, which are all reflected in this light strip.
Features
Using mini 0402 LED as light source, and glue on surface to make the lights more evenly anduniform.
Up to 810 LEDs each meter, only 3.7mm distance between same color LEDs.
Double layer FPC, balancing the voltage dropping, heat dissipation and flexibility.
Compatible with most of the RGB controllers in the markets.
Dimensions
Technical parameters
Temperature Curve
The above curves shows the components' temperatures changes according to the time, after powring within.
The x-axis shows the time from 1st min to 30th min.
The y-axis shows the changes of Resistor, PCB, Glue and Room.
Installation Ways
The recommend running length is 5 meters, for over 5 meters please connect inparallel.
Make sure of the total watts of COB Strip lights is less than 80% of the power supply'smax output.
Match the polarities according to the mark ('+' and '-') in the PCB while connecting.
Applications
--Used in linear lights as lighting source; used for indoor decorations.
Package
